Tube Benders - Flaring - Swaging

Eaton Leonard 3" Head
(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4)
$19,500

Hossfeld No. 1 Universal Manual Bender New
Standard kit No. 05281 which consist of the following - 05255 Main frame, 05260 Swing arm, 05040, 9 Flat surface roller, 05042 11 Square block (2), 05052 17 Regular flat head pin, 05055 19 U Pin, 05057 20 Center Pin, 05166 22 Support plug, 05169 25 Gauge adjusting block, 05170 25A Gauge extension rod, 05172 Circle gauge, 200763 28B6 Hand lever, 20764 28B7 Hand lever pin, 05268 #1 VHS Video, 05271 #1 Operating manual
$786

Hossfeld Pedestal Stand for No. 1
Part No. 05296
$289

Hossfeld No. 2 Hydraulic Powered
Used with some tooling, Has extra long cylinder so you can do larger degree bends then standard hydraulic bender, With stand (PHOTO1) (PHOTO2)
$3,800

Hossfeld No 2 Universal Manual Bender New
Standard kit No. 4600 which consist of the following, 20722 Main frame, 20750 Swinging frame, 20049 9B Flat surface roller, 20054 11B Square block (2), 20084 17B Flat pin, 20097 19B U Pin, 20098 19B4 U Pin w/lug, 20105 20B Center pin, 20691 22B Support lug, 20711 25B Gauge adjusting block, 20713 25B1 Gauge extension rod, 20721 27B Circle gauge, 20760 28B5 Hand lever, 20764 28B7 Hand lever pin, 42015 #2 Instruction manual, 42019 #2 VHS Video
$843

Hossfeld Hydraulic Power Attachment For No. 2 New
Part 49000 which consist of the following, 49001 Hydraulic power unit, 49125 H4 Hydraulic cylinder and hoses, 49270 H52 "L" Swinging frame, 49285 H55 90 Degree cylinder mounting, 49350 Hydraulic conversion hardware
$3,025

Hossfeld Pedestal Stand New
for No. 2 part No. 20768
$264

Pines No. 2 CNC Updated In 2007
All new Adaptive programmable controls/touch screen interface, Nice low hour Machine , Upgraded C axis proportional valve for more accurate bending, S#13900-82063, Model ENC- 075, Left hand bend, 200 Deg max bend, 3" Hole through plane of bend, 6' Travel on plane of bend. Steel tubing, Y.P. to 40,000 PSI, 3" x .109"; Stainless steel, Y.P. to 60,000 PSI, 3"x.065" ; Non-ferrous tubing, Y.P. to 25,000 PSI, 3" x .188" ; Steel pipe, Schedule 80 2" ; Pump motor 20 horsepower; Standard bend radius to centerline 12";  Standard max. tube length over mandrel 120"; Standard carriage travel 72", Machine has not been used since update, Can be seen under power on are floor
(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4) (PHOTO5) (PHOTO6) (PHOTO7) (PHOTO8) (PHOTO9) (PHOTO10) (PHOTO11) (PHOTO12) (PHOTO13) (VIDEO)
$115,000 Sale Price $95,000 Discounted to $75,000


SPECIFICATIONS:
Maximum radius       18"
Max tube length over mandrel  15'
Avg. max bending arm speed   2.3 RPM
Standard operating pressure    3000 PSI
Rotation             Counter-clock
Height floor to centerline of bending form  47"

FEATURES:
• Adaptive Motion controls with touch screen interface
• Machine leak and pressure tested
• Training provided at our facility
• One year warranty on all replaced, restored and all new items

Approximate dimensions 17' x 76" x 52" H
Approximate weight      12,000 lbs.

(PHOTO1) (PHOTO2) (PHOTO3) (PHOTO4) (PHOTO5) (PHOTO6) (PHOTO7) (PHOTO8) (PHOTO9) (PHOTO10) (VIDEO)
P.O.R.


BENDING CAPACITIES:
IPS Extra heavy pipe
3 " Non-ferrous tubing Y.P. to 12,000 PSI
4" OD x .300" Non-ferrous tubing Y.P. to 25,000 PSI
4" OD x . 250" Steel tubing Y.P. to 40,000 PSI
3 1/2" OD x .165"

EQUIPPED WITH:
• Master pressure die bar - Clamp die holder - Fully programmable planing bend head assembly
• Fully programmable hydraulic mandrel extractor
• Fully programmable pressure die assist - Pressure control of clamp, pressure die and assist
• Centralized pressure lubrication system - Inline water/oil heat exchanger - AC main drive motor with electric panel
• New motion control drive cards for all individual servos
• New labeled, harnessed NEMA or IEC rated wiring
• Trailing lead operator station and remote operator pendant
• Operations manual with hydraulic, logic, and electrical schematics
• Inline heat exchanger
